100 Amp DC Circuit Breaker

CNKA 100 amp dc circuit breaker Introduction

CNKA   Easy-to-Maintain 100A DC Circuit Breakers from our China factory offer exceptional current limiting performance. They effectively safeguard relay protection and automated devices from overload, short circuits, and other faults. Our 100A DC circuit breakers are equipped with advanced current limiting and arc extinguishing capabilities, validated through extensive scientific testing. In DC systems below 3000 amperes, they achieve fully selective protection among the main (sub) panel, protection panel, and relay panel.

CNKA 100 amp dc circuit breaker Parameter (Specification)

CNKA 100 amp dc circuit breaker Classification

The principle of DC circuit breaker topologies is intricate. Based on the primary breaking devices used, DC circuit breakers can be categorized into three types: mechanical DC circuit breakers, fully solid-state DC circuit breakers, and hybrid DC circuit breakers that integrate both mechanical and solid-state switches. These variations in structure and operational principles enable different DC circuits to achieve dependable circuit protection and switch control.

CNKA 100 amp dc circuit breaker Details

CNKA 100 amp dc circuit breaker Dimensions and wiring

CNKA 100 amp dc circuit breaker Connection

There are two primary wiring methods for DC circuit breakers: backplane wiring and plug-in wiring. Backplane wiring offers the advantage that during maintenance, only the front power supply needs to be disconnected without the need for rewiring. However, this method requires careful installation according to manufacturer specifications to avoid impacting the circuit breaker's normal operation.

Plug-in wiring, on the other hand, provides greater convenience. When replacing the circuit breaker, simply unplug the old one and insert the new one. It is crucial to securely fasten the plug during installation to minimize contact resistance and enhance overall safety and reliability.
